Description
Product Introduction
AJAX HomeSiren
Product Highlights
Product Catalog
Product Operation Principle
Product Features
Connector for external LED is available. It can be mounted outside your apartment or office to monitor the security system status.
Installation and Set Up Of Product
Ready to operate straight out the box: the battery is already installed, therefore there is no need to disassemble the siren. With one click, it can be connected to the hub in the mobile application. It can be mounted on the SmartBracket in just a few minutes.
Product Specifications
| Type of notification | Acoustic and LED |
| Sound notification volume | 81 – 105 dB at a distance of 1 m (adjustable) |
| Operating frequency of the buzzer | 3.4 ± 0.5 kHz |
| Tamper protection | Yes |
|
Frequency band |
868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the region of sale |
| Compatibility |
Operates only with all Ajax hubs, and range extenders |
|
Maximum RF output power |
Up to 25 mW |
|
Radio signal modulation |
GFSK |
|
Radio signal range |
Up to 2,000 m (any obstacles absent) |
|
Battery supply |
2 × CR123A, 3 V |
|
Battery life |
Up to 5 years |
| Socket for connecting an external light indicator |
Yes (power supply 3 V, 10 mA) |
| Body protection level | IP50 |
| Installation method | Indoors |
|
Operating temperature range |
From -10°С to +40°С |
|
Operating humidity |
Up to 75% |
|
Overall dimensions |
75 × 76 × 27 mm |
|
Weight |
97 g |
| Certification |
Security Grade 2, Environmental Class II in conformity with the requirements of EN 50131-1, EN 50131-4, EN 50131-5-3 |
AJAX HomeSiren User Manual : Click Here
Product Warranty
Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.
What’s in the Box?
- AJAX HomeSiren x 1
- SmartBracket mounting panel x 1
- Battery CR123A (pre-installed) x 2
- LED connection clamp x 1
- Installation Kit x 1
- Quick Start Guide x 1
